800-0300

The 800-0300 is a 3-contact XLR Cable Socket with a black PVC strain-relief. It has high pressure die-cast zinc housing and phosphor bronze contacts. The pressed socket contacts which ‘float' to assist plug mating, also ensuring a positive ‘wrap round' contact with the pin, which can ‘move' with the pins should any movement occur between mating connectors. A single piece latch which is simple to operate, mating smoothly with both lockable and non-latching connectors. The strain relief collet ensures a positive cable grip. The plastic colour coded ring offers a quick and easy system of channel identification.

• Internal design feature allow for a quick and simple insert assembly
• 1500Vrms Test voltage
• 3mΩ Maximum contact resistance
• 1GΩ Insulation resistance
