782250-01
Multif I/O Zařízení, USB-6341, 500 kSPS, 16 bit, 16 Vstupů, 2 Výstupy, 24 I/O, ± 10 V, DAQ Zařízení
Potřebujete další?
| Množství | |
|---|---|
| 1+ | 43 915.080 Kč |
Informace o produktu
Přehled produktu
782250-01 is an USB-6341 multifunction I/O device. It offers analogue I/O, digital I/O, and four 32-bit counters/timers for PWM, encoder, frequency, event counting, and more. On-board NI-STC3 timing and synchronisation technology delivers advanced timing functionality, including independent analogue and digital timing engines and retriggerable measurement tasks. The USB-6341 is well suited for a broad range of applications, from basic data logging to control and test automation. The included NI-DAQmx driver and configuration utility simplify configuration and measurements.
- 16 single ended analogue input channel (16bit analogue resolution, 500kS/s maximum sample rate)
- 2 analogue output channel (900Ks/s maximum update rate), 24 digital input/output channel
- 2047 samples analogue input FIFO buffer size
- 2190μV analogue input absolute accuracy
Poznámky
Board only.
Technické specifikace
Multifunkční I/O Zařízení
16bit
2Zesilovačů
± 200mV až ± 10V
NI DAQ Zařízení
To Be Advised
500kSPS
16Zesilovačů
24I/O
0°C až +45°C
USB-6341
